Product Description

Outdoor heaters have turned verandahs, decks and patios into an all-season source of pleasure and relaxation for thousands of home owners. Today’s outdoor heaters are safe, quiet and affordable. Now you can relax in the spa, use the barbecue or simple unwind on the patio whatever the season or the weather.

HEATSTRIP is an Australian designed, engineered and assembled range of high intensity electric, infra-red radiant heaters suitable for tough outdoor and indoor heating applications.

Whilst convection heaters heat the air in between objects, radiant heaters heat the surface of the objects themselves. Heatstrip electric radiant heaters are more effective within an outdoor or indoor area because they provide targeted warmth directly to the people and objects in their path.

Using the radiant heating principle, HEATSTRIP can provide effective and energy efficient comfort heating for outdoor (undercover and open) and indoor open areas making use of the outdoor areas of many types of venues through all seasons. Within your home HEATSTRIP can provide comfort heating for undercover alfresco dining an BBQ areas, patios, verandahs, courtyards and balconies.

Share this:


















Mounting Options

The installation is simple and easy with the standard mounting brackets supplied. For more challenging locations, there are a range of mounting options available – refer to below diagrams.

The Heatstrip Max can be mounted directly to the ceiling; angled downwards on a wall; suspended on chains or poles; attached to beams/rafters; or 2 units together (refer to the Product Manual for more detailed information on each mounting option).

Selection guide

General recommendations for HEATSTRIP Max:

• Ideal mounting height: 2.3m to 2.8m. Maximum is 3.0m in an outdoor environment and 3.5m indoors
• Ideal mounting location: ceiling mounted, directly above area to be heated (eg. above a table), however can also be mounted on a wall and angled downwards.

The below table outlines the coverage of each Heatstrip Max model (in m²), based on 3 different scenarios. For example, in an outdoor area that is protected from prevailing winds by walls, café blinds etc, (eg outdoor enclosed), Model THX 2400 will cover 10m² and Model THX 3600 will cover 15m². This data is based on direct overhead ceiling mounting. If the heaters are wall mounted, the radiant footprint will be reduced.
